Paint DIN Cup/ DIN Viscosity Cups /DIN Portable Viscosity Cup

Portable Viscosity Cup Aluminum DIN Immersion Viscometer 4mm 100ml DIN Flow Cup for Testing the Viscosity of Liquid (Ink Paint Varnish) DIN Immersion Flow Cup Technical Parameters: Portable DIN cup Model No. : 4# 1. DIN immersion cup Cup material: Aluminum 2. din flow viscosity cup Capacity:100ml. 3. Din viscosity flow cup Cupinnerdiameter:50±0.05mm 4. Professional DIN Viscosity Flow Cup Efflux Aperture Length :10±0.1mm 5. DIN cup viscosity measurement Cup body width 55 mm, cup height 73 mm, total length 270 mm 6. portable DIN viscosity cup 4mm Mouth hole inner diameter: Φ4 ± 0.02mm 7. Ideal measuring range: 300 ～ 1500 cSt Din viscosity flow cups used to determine the viscosity of inks, coatings, paints. It is opened by the bottom orifice, the refining capacity of 100ml of high-quality aluminum cup. Din flow viscosity cup Aluminum cup body, stainless steel nozzle /outlet, stainless steel handle. Portable Viscosity Cup Aluminum DIN Immersion Viscometer DIN Flow Cup 4mm 100ml. Portable DIN viscosity cup 4mm
